    SDH2105U
    HIGH VOLTAGE HALF BRIDGE DRIVER

        The SDH2105U is a half bridge driver for high voltage N-type power MOSFETs and IGBTs. The built-in undervoltage lockout prevents the power device from working under low control voltage; high/low side input interlock protection and built-in dead time are available to avoid the simultaneous conduction of both high side and low side MOSFETs.

    Main feature

    • High-side floating supply absolute voltage: 600V

    • Output current: +0.35A/-0.70A

    • 3.3V/5V/15V input logic compatible

    • High-/low-side double high input interlock protection

    • Under-voltage (UV) lockout

    • Built-in dead time

    • dV/dt immune

    Ordering Information
    Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
    SDH2105U SOP-8-225-1.27 SDH2105U Halogen free Tube
    SDH2105UTR SOP-8-225-1.27 SDH2105U Halogen free Tape&Reel
    Block Diagram
