    SDH2103U
    HIGH VOLTAGE HALF BRIDGE DRIVER

        The SDH2103U is high voltage N-type power MOSFET and IGBT half bridge driver, whose built-in undervoltage lockout prevents the power device from working under low control voltage, and high/low side input interlock protection and internal dead time avoids the simultaneous conduction of both high side and low side MOSFETs.

    Main feature

    • High-side floating supply absolute voltage:600V

    • Output current:+0.35A / -0.70A

    • 3.3V / 5V / 15V input logic compatible

    • Built-in dead time

    • High-/low-side interlock protection

    • Under-voltage (UV) lockout

    • dV/dt immune

    Ordering Information
    Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
    SDH2103U SOP-8-225-1.27 SDH2103U Halogen free Tube
    SDH2103UTR SOP-8-225-1.27 SDH2103U Halogen free Tape & Reel
    Block Diagram


    Documents
    title Types of Size (KB) date Download the latest English version
    SDH2103U PDF 191 2023-12-12 SDH2103U 简要版说明书
