      SDM15G60FC
      600V/15A 3-PHASE FULL-BRIDGE DRIVER (INTELLIGENT POWER MODULE)

          SDM15G60FC is a 3-phase brushless DC motor driver with high integration and high reliability for low power inverter driving such as air conditioner, refrigerator and dishwasher. It has embedded six low-loss IGBTs and 3-phase full-bridge gate drivers with high voltage.

          The under voltage and short circuit protections integrated make the circuit work safely in a wide range. The current of each phase can be detected separately because there is one independent negative DC terminal for each phase.

          SDM15G60FC uses high-insulation design, compact package and carries heat easily, which makes it easy to use especially for compact installation applications.

      Main feature

      • Built-in low-loss 600V/15A IGBT;

      • Built-in high-voltage integrated circuit of gate driver;

      • Built-in under voltage protection, over current protection and temperature output;

      • Built-in bootstrap diode with current limiting resistor;

      • Compatible with 3.3V, 5V MCU interface, active high;

      • Three independent negative DC terminal for inverter current detection;

      • Alarm signal: for low-side under voltage, over temperature and short circuit protections;

      • Very low thermal resistance using Al2O3 DBC substrate;

      • Insulation level: 1500Vrms/min.

      Ordering Information
      Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
      SDM15G60FC DIP-24HL SDM15G60FC Halogen free Tube
      Block Diagram


      Documents
      title Types of Size (KB) date Download the latest English version
      SDM15G60FC PDF 373 2023-02-24 SDM15G60FC 简要版说明书
